51.03m Gearless Cargo Vessel

Listing ID - 5569
Description	51.03m Gearless Cargo Vessel
Date Launched	1992
Length	51.03m (167ft 5.1in)
Beam	8.30m (27ft 2.8in)
Draft	4.05m (13ft 3.4in)
Location	New Zealand
Broker	Ivan Colaco ivan.colaco@seaboatsbrokers.com +61 401 695 814
Price	USD 750,000
View As PDF

Kind of Vessel: Gearless Cargo Vessel (Box hold)

Registry Port: Nelson, New Zealand

Class: NZ Offshore

GT: 561 tons

Deadweight: 868 tons

Built: Feb. 28,1992

LOA: 51.03m

Beam: 8.30m

Depth: 5.10m

Draft: 4.05m

Hatch / Hold Size: 27m x 6.30m x 5.2m folding type steel hatch covers

Main Engine: 550ps x 350 rpm 6M26KGHS-01 Matsui Iron Works (Nov. 1991)

Supercharger: Exhaust Gas Turbine VTR-200 Niigata

Air Cooler: Surface cooling type 22.14m2 Tokyo radiator

Remote Control System: Air type FG-1A Matsui Iron Works

Gear Box: MN630 Niigata Converter

Propeller: 4 blades x ALB x Dia 1750mm x Pitch 1000mm Fixed Pitch Mikado

Auxiliary Engine: 62ps x 1800rpm 4CHL-TN Yanmar + Turbo RHB6 IHI (Dec. 1991) Deutz 40kva air cooled harbor generator. (Replaced with new engine 2013) 4 ps x 2200rpm NMSH Mitsubishi (for Air Compressor) (Dec. 1990)

Generator: 50kva x 1800rpm x 225/130v HS-ZK Tokyo Electric (June, 1991) 30kva x 1800rpm (Harbour generator) 1992 40kva x 1800rpm x 225/130v TEW26A driven with M/Eng by Belt Taiyo Electric (Dec. 1990)

Air Compressor: 30kg/cm² x Motor 3.7kw Matsubara 30kg/cm² x Diesel 4ps Sabwa

Windlass: 2.0/1.0T x 10/20 M/M. x 2 sets, Mooring Winch 2.0/1.0T x 15/30 M/M. x 1set Kosei

Ballast: FPT 15.80 No.1 18.20 x 2 No.2 37.90 x 2, No.3 41.20 x 2 Total 210.40m³

Fresh water (APT): 8.25m³

Fuel Oil: 11.80 x 2 Total 23.60m³ (100%)

Fuel Consumption: 80 liter/hour 1.92m³/day on 330rpm

Nautical Apparatus

Steering Gear TS-020 Tokimec

Magnet Compass T-125

Gyro Compass ES-11A + Auto Pilot Tokimec

Radar 1942 Mark-2 Furuno

JRC JMA 5322-7BB

GPS Plotter Multi-Scale GP-1250 Furuno

Color Video Sounder PCV-561 Furuno

Navtex NX-600 Furuno

VHF Radio JHS-33A JRC

Nany N Satellite, A.I.S System.

Accommodation room/Complement

4 Cabins / 4 crew

Remarks

FPT: (Clean)

Ballast No. 1, 2, 3, all ballast pipe replaced with new one in 2003 when annual dock.

Ballast No. 1, 2, 3, all ballast tank coated with TAR in last Special Survey in 2004.

All ballast Air Extractor pipe replaced with Stainless Steel

On Deck all Scupper replaced with Stainless steel.

Ballast tanks are in good condition,

Newly in Survey to NZ Coastal Class, April 2008. Including slipping, shaft/rudder inspection and underwater coatings. Upgraded to NZ offshore in December 08. Further updates carried out in 2012 to increase vessels reserve buoyancy and load line.

Vessel subject to 5-year survey programmed under Maritime New Zealand. This includes a full out of water survey including propeller shaft inspection every 5 years and an intermediate out of water survey half way through this period.

Propeller shaft renewed in 2021.

All engines use Low Sulphur Fuel.

The details of all vessels are offered in good faith but we cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. Any buyer should instruct their agents, or their surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to sale, price change, location or withdrawal without notice.
