Registry/ Delivery:  Australia / December 2012

Official Number:  860899

Call sign:  VJN4417

IMO Number: 9468207

Length: 28m (91ft 10in)

Breadth: 11m (36ft)

Depth Moulded: 3.25m (10ft 7in)

Designed Draft: 2.275m (7ft 5in)

Classification:  ABS+A1 (E), Towing Vessel, +AMS

GRT/NRT:  247/74 tons

FO/FW Tank:  141.20 m³ / 53.70 m³

Total Deck Space:  Approx. 110m²

Free Run Speed Approx.: 10 knots

Bollard Pull: 18 tons

ENGINE ROOM

Fuel Oil Transfer Pump - 25 m³/hr

Sewage Treatment Plant w/ Holding Tank

Blower fan – 2 x 19” for Engine Room

Fitted with SOLAS/Class Approved Co2 Fire Suppression System

MAIN ENGINES / GENERATORS

Main Engine: 2 x Caterpillar 3412C DITA 720bhp @ 1800rpm

Gear Box:  Ratio = 4.5:1

Generator:  2 x Caterpillar 3406C DITA @ 150ekW/415V/3PH/50Hz/1500rpm

Propeller: 2 x Fixed Pitched 4 blade (1400mm) with Kort Nozzles

DECK MACHINERY

2 x Anchor Windlass: Electrical hydraulic anchor windlass having capacity 2.0 tons @ 10m/min; Single gypsy suitable for 19mm dia. Stud link chain, 2 x 300kg Stockless Anchors

2 x Crane:  FASSI F1100AXP-FM.24 Knuckle Boom Crane (Bow & Aft), Max 25 ton @ 3.5m, Min 8 ton @ 11.25m, Individual Hand-held Remote Control

Towing Hook:  Towing Hook 30 ton WLL with hydraulic emergency release

Towing Winch: 1 x ME S’pore 25-ton Single Drum Winch with 50-ton Brake holding capacity; Local, Remote & Pendant Control

Towing Wire:  32mm dia. X 400m (6x36) IWRC EEIPS RHRL Galvanized Wire Rope

A-Frame/Rollers:  Class Approved Anchor Handling A-Frame

Rollers:  Bow & Stern Rollers Fitted

Controls: Wheelhouse & Steering Gear Control – Fore & Aft

NAVIGATION / COMMUNICATION EQUIPMENT

Radar:  Furuno FR 8062

VHF:  Furuno Make

GMDSS Inmarsat C Sys.:  Furuno A1+A2+A3

SSB Radio:  Furuno Make

GPS Navigator:  Furuno GP-150

GPS Chart Plotter:  Lowrance HDS-10

Magnetic Compass: DAIKO SR-150PK

Speed Log: Furuno Make

Universal AIS:  Furuno FA-150

Echo Sounder: Furuno FE-700

Navtex Receiver: Furuno NX-700

PA system: Huayuan

Intercom: Huayuan

Wind Speedometer: Furuno FI-50

Facsimile Receiver:  Furuno Fax-400

ACCOMMODATION / LIFE-SAVING & FIRE FIGHTING EQUIPMENT

Accommodation:  1 x 1 man (Captain); 1 x 2 men; 2 x 4 men

Life rafts:  2 x 15 men SOLAS (Bridge & Main Deck)

EPIRB:  McMurdo E5 Smartfind 406

SART: McMurdo S4 Rescue SART

Pyrotechnics, Life-buoys, Various Fire Extinguishers. Co2 Suppression System, Fireman’s Outfit & BA Set Fitted to Statutory Req. of S’pore Non-Convention Vessels, SOLAS & Australian regulations
