NEW BUILD - 12.80m Pilot Boat

Listing ID - 5808
Description	12.80m Pilot Boat
Date Launched	Built to Order
Length	12.80m (41ft 12in)
Beam	4.00m (13ft 1.4in)
Draft	1.20m (3ft 11.2in)
Location	UK
Broker	Richard Pierrepont richard.pierrepont@seaboatsbrokers.com +44 7798 607 323
Price	POA
View As PDF

PROVEN HALMATIC NELSON HULL

FLOATING WHEELHOUSE

TWIN ENGINES

ROBUST COMPOSITE CONSTRUCTION

OPTIMISED PILOT TRANSFER DECK

RINA CERTIFICATION / WORKBOAT CODE 3

The HN-42 Pilot Boat is built today by Absolute Marine using the famous Nelson hull design. This makes the HN-42 a very capable vessel and is proven in operation with pilot services around the world.

The HN-42 is noted for its exceptionally soft ride, excellent handling in difficult sea conditions and for the

predictable handling during ship boardings. They are built to Classification Society-approved drawings and are equipped to comply with the customer’s local flag approvals.

MAIN CRITERIA

Length Overall (LOA): 12.80m

Length On Water Line (LWL): 11.45m

Beam: 4.00m

Draft: 1.20m

Displacement: 15 Tonnes (Approx)

Air Draft (mast down): 3.38m

Fuel Tank Capacity: 2,500ltrs (Approx)

Design & Build Standard: Rina Certification

SUMMARY SPECIFICATION DETAILS

HULL & DECK COLOURS

Hull – Black

Deck – White

Superstructure – White

Non-slip deck – Painted

Antifouling Paint – Crimson

Boot-top paint – White

ENGINE & RELATED SYSTEMS

Engine options available, *including Volvo, Nanni, Caterpillar

*Note: other engine types are subject to compatibility (priced separately)

Conventional shafts and rudders

Heavy duty P brackets and contra rotating nickel aluminium bronze propellers

Separate fuel tanks for each engine

Inspection lids for tank cleaning

Each engine has its own primary and secondary fuel filter

Single station hydraulic steering

Electrical (24V DC)

2 x Batteries for engine starting

4 x Batteries providing power for domestic equipment

Systems control/ monitored by CZone digital switching via 7inch display

All battery circuits are individually isolated with an emergency parallel link between engines

Horn

Navigation lights

Pilot Lights

Deck Lighting

LED overhead interior lights

Chart light

12-volt power socket

Pantograph wipers

Screen washers

Electrical (AC)

Shore Power Connection

Shore power lead

Battery Charger

4 x AC power sockets

Interior Fit-Out – Wheelhouse

Helm to starboard side

1 x Helm seat

3 x Crew seat

2 x Bench seats

DECK EQUIPMENT

• MOB davit

• 3 – Stainless steel bollards

• 2 – Fairleads, foredeck

• Mast in black powder coat finish

NAVIGATION SYSTEMS

• Multi-Function Display - 4” Screen - Wind, Speed, Depth & Temp

• VHF – DVC

• AIS700 - Class B with splitter

Note: Navigation system options are available, subject to customer requirements (priced separately)

Fire detection/fighting

• Fire detection system

• Portable fire extinguishers as appropriate

• Automatic engine room fire extinguishers

• Fire Fighting system including pump, deck hydrant, hose

GENERAL

• Echomax Radar Reflector

• Anchor & Chain

• 6 mooring warps

• Magnetic Compass

• Manual & electric bilge pumping

• Bilge water level alarm system

NOTE:

Other optional items and equipment are available on request.

This summary specification is for illustration purposes only and is non-contractual.
