48m AHTS from SeaBoats

48m AHTS

Listing ID - 5580
Description	48m Offshore - AHTS
Date Launched	2002
Length	48m (157ft 5.7in)
Beam	13m (42ft 7.8in)
Draft	52m (170ft 7.2in)
Note	Engine: 2x MaK
Location	Middle East
Price	4,000,000 USD
View As PDF

Built year / Place: 2002 / Singapore

Hull material: Steel

Flag: Cameroon

Class Society and Notation: Croatian Register Shipping, Unrestricted Service

Next SS: 03/2026

PRINCIPLE DIMENSIONS

Length Overall: 48m

Breadth: 13m

Depth: 6m

Draft: 52m

NT: 306 tons

GT: 1021 tons

DWT: 700 tons

MACHINERY & PROPULSION

Total power output: 8000 bhp

Main Engine: 2x MAK

Main Propulsion System: 2 x 3500 mm diameter, 4 Blades, CPP

Auxiliary engine: 1x 99 KW , CAT3306 DITA, 3 x 400 kW, CAT 3412

Speed cruising: 13 knots

CARGO AND TANKS CAPACITIES

Fuel tanks capacity: 780 m3

Fresh Water tanks capacity: 229m3

ADDITIONAL INFORMATION

Bow Thruster: 1 x 500 bhp BRUNVOLL type CPP - thrust 6.3 T

Wire Storage Reels: 2 x 9.1T line pull at 0.51nVimin hydraulic wire storage reals of 1200m x 60mm dia.1 x 18.2T tine pull at 0-21rrihnin hydraulic wire storage reel with capacity of 1200m x 60mm dia SWR,One storage reel will contain 1200 M X 60 MM of Spare towing wire and one reel should have various sizes of pendant wires

BP 112 tons

Towing Pins & Shark jaws: KARM FORK combination unit with 2 towing pins & 2 shark jaws

Anchor Windlass: Hydraulic 8.5T@ 13 m/min BRATVAAG

Anchors: 2 x 1440kg slockless anchors

Anchor chain: 2 x 275m x 34mm diameter U2 steel stud link chain lube

Crane: North American Crane model MCT 2•2568.capacity 2.7T @ 20.7m / 10T @ 7.6m

Radar: 2 x IMO approved X. band marine radar c/w 6.5ft scanner and performance monitor. FURUNO model FR2115 (#1)&, FR-1510 MIKIII (#2)

SSB: Radio console, FURUNO RC- 1500-IT-24V DC/240V DC/240V AC with manual cover to emergency supply antenna feeder trough Insulators. c/w DSC & NBDP to meet GMDSS requirements FURUNO model FS-1562'-25 (250W), 200 CHS Area A3

VHF: 2 x VHF/FM multi-channel marine radio telephones FURUNO model FM-8.500- 25W

Gyro 8 Automatic Pilot: 1 set-fitted. Gyro-Tokimec TG6000.Autopilot-Fururio Model FAP-330

Main Engines - 22 M/T MGO and 80 litres lube oil per 24 hours consumption @ full power.

14 T MGO and 60 litres lube oil per 24 hours@ economic cruising speed of 10 knots

Generator- 800 litres MGO and 10 litres lube oil consumption per 24 hours

Propulsion- 2 x 3500 mm diameter, 4 Blades, CPP with Kort nozzle

Steering Gear: Electro hydraulic. 11 Ton torque

Fuel oil purifier: 1 x SJ10F Mitsubishi self-cleaning fuel oil purifier

oil purifier: 1 x –SJ15F Mitsubishi self-cleaning lube

Weather Facsimile: 1 x FURUNO FAX-207

Other Navigation/ Communication Equipment INMARSAT-C, EPIRB, Radar Transponder, P.A. System c/w Fog Horn Signal, Navtex receiver. GPS Navigator, 1 x Satellite FBB Tel & Email, Echo Sounder, (colour). 2 VHF walkie talkie

Dispersant Booms: 2 x 8m dispersant booms fitted

Fire Monitors: 2 fixed foam/water fire monitors of 10000 liters/min each @ 130m head capacity. 1 x Fire Pump of 1400rn'/hour each

Pondering: Flat bar doubler plates of 30 x 350mm cross section welded to side shell. & Tyre fenders around

Rescue Boat: 1 x 6 men

The details of all vessels are offered in good faith but we cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. Any buyer should instruct their agents, or their surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to sale, price change, location or withdrawal without notice.
