44.45m Surface Freezer Longliner

Listing ID - 5406
Description	44.45m Surface Freezer Longliner
Date Launched	2003
Length	44.45m (145ft 10in)
Beam	9.20m (30ft 2in)
Draft	6.00m (19ft 8.2in)
Note	Engine: 3 x VOLVO: TAMD103A, Power: 306 HP at 1.500 r.p.m.
Location	Spain
Broker	Georgi Savchev georgi.savchev@seaboatsbrokers.com +359 88 7228674
View As PDF

Type Of Vessel: Surface Freezer Longliner

Hull: Steel

Year Of Construction & Flag: 2003, Spain

Classification: Bureau Veritas

DIMENSIONES:

Overall Length (LOA): 44.45m

Length between perpendiculars(LBP): 36.50m

Beam: 9.20m

Depth: 6.00m

Draft: 3.90m

TONNAGE: 636 GT / 191 NT

CAPACITIES:

Total Fish Hold capacity: 250 tons

Fuel capacity: 366,1 m³

Oil capacity: 5,9 m³

Average Fuel Consumption: 1.400-1.500 l/day

Fresh Water capacity: 6,5 m³

PROPULSION SYSTEM:

Main Engine: ABC model 6MDZC-600-135A Serial Nº:12652

Power: 1.224 HP / 878 KW at 750 r.p.m.

Reduction Gear: REINTJES WAF1542, Ratio: 3,039/1

Propeller Shaft Ø: 197 mm

AUXILIARY ENGINES:

3 x VOLVO: TAMD103A, Power: 306 HP at 1.500 r.p.m.

3 x Alternators: STAMFORD, Power: 262,5 Kva, 380 V

FISH AND DECK MACHINERY:

• 1 x Bow Crane: TOIMIL T/10500, Lifting capacity: 20 m

• 1 x Stern Crane: TOIMIL T/700M

• 1 x Servo motor: FLUIDMECANICA, Lifting capacity: 3,5 Tm (2x5,5HP)

• 2 x Winches: HIVISA, 2*30 HP / 1.475 r.p.m.

• 2 x Haulers: HIVISA , 2*15 HP / 1.470 r.p.m.

• 3 x Bilge Pumps: AZCUE, Power: 7,50 HP; Flow: 30 m³/h; Pressure: 28 bar

• 1 x Fuel Transfer Pump: AZCUE, Power: 5,50 HP; Flow: 20 m³/h; Pressure: 25 bar

• 2 x Fresh/Salt Water Pumps: AZCUE, Power: 2 HP; Flow: 7 m³/h; Pressure: 30 bar

• 2 x Air Compressors: ATLAS COPCO, Power 7,50 HP

REFRIGERATION SYSTEM:

Manufacturer: CLIMAFRÍO. Cooling System DIRECT EXPANSION. Freezing Capacity: 10 tons/day

2 x FREEZING TUNNELS

3 x REFRIGERATION COMPRESSORS: 2 x BITZER OSN-7461 (22 Kg/ Cm²)

1 x BITZER OSN-536

INTEGASA, 55,2+29,44 Kw

3 x CONDENSERS: 4 x FANS: WOODS, 10.000 m³/h; 3,8 Kw

ELECTRONIC EQUIPMENT:

Modern &Fully Equipped:

• Echo Sounder: FURUNO FCV1200LM

• Depth Sounder: FURUNO FE700, 50 Kw

• NAVTEX: NAV5

• 2 x Radars: FURUNI FR1225 MK3 and FR7062

• 2 x GPS: FURUNO GP-80 y GP32

• 2 x Autopilots: ROBERTSON AP45

• 2 x Plotters: SODENA SEAWAVE WIN PRO 11” color

• Scrambler: SAILOR CRY-2001

ACCOMODATION:

23 Crew Members

* Last inspection carried out in October 2023

The details of all vessels are offered in good faith but we cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. Any buyer should instruct their agents, or their surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to sale, price change, location or withdrawal without notice.
