Built: Dec., 2008

G.R.T: 387T

N.T: 116T

Class: ABS

Notation: A1, Towing Vessel, AMS



DIMENSIONS:

Length Overall: 36m (118ft)

Length B.P: 33.28m (109ft 2in)

Breadth Moulded: 9.80m (32ft)

Depth Moulded: 4.30m (14ft)

Draft Moulded: 3.50m (11ft 5in)



MACHINERY:

Main Engines: 2 X 1000 BHP / Caterpillar 3508 B

Auxiliary Engines: 2 X 215 kw / Caterpillar 3406 C

Bow Thruster: 1X 200 BHP Electrical motor driven thrust.

Propellers: 2 X Fixed Pitch Propeller.

Rudders: Conventional; 2 X Stockless anchors with 15 lengths

Anchors: 22 mm dia. Stud link chain.

Maximum Speed: 12.00 Knots



CAPACITY:

Deck Strength: 2.5 Tons/m²

Clear Deck Area: 130 m²

Fuel Oil: 260.8 m³

Fresh Water: 99.124 m³

Chiller: 6 m³

Freezer: 6m³



DISCHARGE RATE:

Fuel Oil: 35 m³/ hr at 40 m head

Portable Water: 35 m³/hr at 40m head



TOWING HANDLING EQUIPMENT

Bollard Pull: 29.81 T

Towing/ Anchor Handling: 1 X 30 Tons Brake hold 40 Tons.

Towing Winch: Single Drum, Waterfall arrangement.

Drum Capacity: 33 mm dia. X 500m



DECK & AUXILIARY EQUIPMENT

Anchor Windlass: 1 X 3 Tons at 12 m/min

Deck Crane: 1 X 3T@ 6M



ACCOMMODATION

2 X 1 Man

5 X 2 Men

2 X 4 Men

Total: 20 men



RADIO & NAVIGATION EQUIPMENT

SSB: 1 X JRC

VHF: 3 X JHS-7E-Furuno

Radar: 2 X JMA-5210-6-JRC

Echo Sounder: 1 X JEF-380-JRC

Gyro Compass: 1 X GMZ900-JRC

GMDSS: 1 x JRC-JSB-196 GM

Magnetic Compass: 1 x JRC

Speed Log: 1 x JRC-JLN-205

Auto Pilot: 1 x JRC

Navtex Receiver: 1 x JRC, NCR-333

DGPS Navigation: 1 x JRC, J-NAV 500

AIS: 1 x JRC, JHS-182

EPIRB / SART: 1 x JRC, JQE -103

Joy Stick Control: 2 X Palmarine

Weather Facsimile: 1 X JRC JAX-9B

VDR



FIRE FIGHTING EQUIPMENT:

External:

Fire Pump: 1 X 650 m3/hr at 10 bar.

Fire Monitors: 2 water monitors (one with Double barrel for foam discharge).

Fixed Water Spraying: All round water curtain 35 m3/hr.



Internal:

Co2 system for E/R: Fixed central bank.

GS & Fire Pump: 1 x 35 m3 /hr at 33 m head.

Emergency Fire Pump: 1 X 25 m3/hr at 30 m head.
