Listing ID - 4110 | |
---|---|
Description | NEW BUILD - 22m Landing Craft |
Date Launched | Built to Order |
Length | 22.13m (72ft 7in) |
Beam | 7.5m (24ft 7in) |
Draft | 2.2m (7ft 2in) |
Location | ex shipyard, United Kingdom |
Broker | Richard Pierrepont richard.pierrepont@seaboatsbrokers.com +44 7798 607 323 |
View As PDF |
Vessel Type: Twin screw monohull landing craft
Classification: UK MCA Workboat Code of Practice (MGN280) CAT 2
Area of Operation: 60nm from safe haven
Crew: 3 Crew
Construction: Welded steel
Length (OA): 22.13 m
Beam (moulded): 7.5 m
Depth (moulded): 2.0 m
Draft Aft(Loaded) : 2.2 m
Displacement (Lightship): TBC tonnes
Air Draft: 8.0m approx.
Cargo Deck Strength: 1.5t/m2
Free Running Speed (Loaded): 9 knots Approx.
Cargo Capacity: 50 tonnes total (with restricted crane operations)
Main Engines: Doosan L126TIH – 2 x 360hp @ 2000rpm
Stern Gear: Grease lubricated stern glands, twin props
Steering: 24v Hydraulic powered, twin rudder
Deck Crane: Heila HLRM 35/5S (1550kg @ 14.79m)
Electrics: 24V DC, 240V & 415v AC 50Hz
The details of all vessels are offered in good faith but we cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. Any buyer should instruct their agents, or their surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to sale, price change, location or withdrawal without notice.
