Built (year and place): 2012, Netherlands

Hull material: Steel

Class Society and Notation:

Bureau Veritas l HULL-MACH Tug

Unrestricted Navigation AUT-UMS

Nat. Authorities MCA workboat class 1 @ 150 nm from safe haven

Last DD - Next DD: January 2014 - January 2017

Next SS: January 2017

Next Annual Survey: April 2016

Principle Dimensions

Length Overall: 24.07m

Load Line Length: 23.11m

Breadth: 12.97m

Depth at sides: 4.00m

Draft (max / min): 2.7m / 3.8m

GT (tons): 199.80 tons

Bollard Pull (certified): 53.4 tons

Bollard Pull Astern: 35.0 tons

Machinery and Propulsion

Total power output (HP): 3820 hp

Main Engine(s) (make, type): 2 x Caterpillar 3512 B TA

Gearboxes: 2 x Reintjes WAF 773 7.087:1

Main Propulsion System: 2 x F.P.P. in nozzles 2400mm

Auxiliary engine(s): 2 x Caterpillar C 04.4, 107kVA each; Caterpillar – C 04.4, 60kVA Harbour set; Caterpillar C-32 TTA, 970kW at 1800 rpm Hydraulic power; Fuel & fresh water – 50m³/hr Transfer Pumps

Bow Thruster (if any): 2 x Kalkman 257kW in pushbows

Rudders: 2 x Independent fishtail 45 degrees

Speed (cruising – maximum): 9.5 – 10.6 knots

Accommodation

Total cabins: 4

Seats for passengers/crew: 8

Others: Comfortable heated and air-conditioned accommodation, galley, sanitary facilities, etc

Lifesaving Equipment

8 x Lifejackets

8 x Immersion suits

2 x 8 persons Life raft capacity

Class A First Aid kit Size type of medical kit / facilities

Approved for UK MCA Cat.1 vessel, 150nm from safe haven

Additional Information

Navis JP3000 DP System

Fitted with a 60t Portal A frame for ploughing, etc.

Cargo, Tanks Capacities & Range at Sea

Deck Cargo (tons): approx. 100 tons with half tanks

Deck Area (m²): about 180m²

Deck Strength (tons/m²): 10t/m²

Fuel Tanks Capacity: 120m³

Fresh Water tanks capacity: 51.10m³

Ballast Tanks Capacity: 30.00m³

Black/grey water: 7.30m³

Dirty Oil: 3.60m³

Range at sea (nm): 3500nm

Endurance (days): 30 days

Fuel consumptions: economical  285 ltr/hr @ 8.5 kts; Site work light duties 5,500 lt/wk

Navigation and Radio Equipment

1 x JRC NCR 333 Navtex

1 x Alphacall MF (9 Stations) Intercom

2 x Sailor RT 6222 / DSC VHF

3 x Icom IC-M71 VHF Handheld

2 x Sailor SP3520 VHF GMDSS

2 x Sailor TT6110 Inmarsat-C

1 x JRC JHS 182 Class A AIS

1 x Sailor System TT6000 SSB

1 x APC 1600W – 220V UPS system

2 x JMA 5208-6 inches + 4 inches (ARPA) Radar system

1 x Caessens & Plath Compass

1 x Alphaminicourse Gyrocompass

2 x JRC JFE-380 in pushbows Echo sounder

2 x JRC JLR7800 DGPS

1 x JRC JLN 205 Speed log

1 x Navisailor 4000ECS + Backup Chart Plotter

1 x Alphatron Multicourse Autopilot

4 x Alphatron Eclips CCTV

1 x Intellian 16p Sat TV

GSM cellphone, email & internet (coastal)

Deck and Towing, Lifting, Mooring Equipment

2 x 200.000 4S / 10.5T @ 16m Deck Cranes

50T pull, 125T brake / 700m x 48mm Towing winch

100T pull, 150T brake / 150m x 48mm Anchor handling

4 x 13T pull / 200m x 22mm + 19mm ground chain

Tugger/Mooring winches

4 x 1000kg Delta Flippers + cowcatchers mooring spread

Shark Jaw – Triplex H -200, Guide Pins – Triplex S-65

Side Pins – WK 400 Pop-ups fore deck

WK Triple pin type Pop-ups aft deck

Mampaey 45T Towing hook

100T SWL 6m,
1200mm Bow roller

60T SWL 2m,
760mm Stern roller

WK 5 tons Capstan
