New Zealand built 26m (84ft) Luxury Pilothouse Yacht .



Listing ID:
576863

DESCRIPTION:New Zealand built 26m (84ft) Luxury pilothouse Yacht
DATE LAUNCHED:2004
BEAM:6.50m
DRAFT:3.20m
DISPLACEMENT:73 tonnes
LOCATION:San Remo, Italy
BROKER:Clive Bennett
PRICE:New Asking Price : € 1 590 000 EUR (VAT paid)
LENGTH:25.65m (84ft)

Send Enquiry


General Description:

Please scroll down to view more photos

Builder: FITZROY YACHTS, New Zealand
Type: Aluminium Cutter Sloop
Naval architect: JUDEL VROLICK, Bremerhaven
Designer: DICK YOUNG DESIGN, London
Length: 25.65m (84ft)
Beam: 6.5 metres
Draft:  3.2 metres
Displacement: 73 tonnes
Guests: 10
Year:  2004

Overview:

Neptune is designed for extended ocean cruising and is fabricated in ‘Alustar’ aluminium as a custom built yacht with spacious accommodation. This includes a three-cabin layout aft, the owner and all guest’s cabins each with private ensuite. The two forward crew cabins also have separate facilities. The generous main saloon provides a dining area to starboard and comfortable lounge.

The pilothouse incorporates an additional dining area, chart table and inside steering position. Fully retractable side windows provide a pleasant open aspect and enhance the panoramic views afforded from the deckhouse.

Interior joinery is American walnut to complement the red leather upholstery and other quality textiles used throughout. Two Charles Eames designed loungers placed in the lower saloon complete a very luxurious fit out.

In 2017, the new owner decided to refit extensively in order to look  like new and to be able to sail around the world. She is now back in turn key condition and in compliance with the commercial French Registry.


Specifications:
Spars: SOUTHERN SPARS carbon-fibre mast and boom
Hydraulic reef system, main sail in boom (mast: 33.5 metres above water line)
Standing rigging: Rod rigging
Running rigging: Spectra
Furlers: Head sail on forestay / RECKMANN FURLER system
Stay sail on inner stay / RECKMANN FURLER system

SAILS AND RIGGING
Sails:  one complete set of sails (mostly new from 2011 by ZAOLI SAILS)
Sail area upwind: 385 m² - downwind: 734 m²
Main sail: approx 177 sqm by ZAOLI SAILS – new 2011
Genoa sail: approx 208 sqm by ZAOLI SAILS – new 2011
Staysail: approx   91 sqm by ZAOLI SAILS – new 2011
Storm sail: approx   46 sqm
Asymmetrical spinnaker : approx 526 sqm by DOYLE


Deck hardware: HARKEN 8 hydraulic winches
Captive Winch for Mainsail
Windlass: CQR Niro anchor 108 kg, with 120m chain, 16mm hydraulic anchor
windlass, stern & reserve anchor

Steering Mechanism: Double steering stand in cockpit
WHITE LOCK System with instrument consoles, second steering stand
in deckhouse

Engine: LUGGER 222 kw / 300 PS - 3.376 hours on July 2011
+ PTO (Hydraulic System)
Propulsion:   HUNDESTEDT PH 5 Multi-pitch propeller system
Performances: 9,5 knots @ cruising speed
Consumption: L / H @ cruising speed (including generator)
Range: 2.200 NM @ cruising speed

Bow Thruster: LEWMAR 30 kw, extensible, hydraulic drive

Generator: NORTHERN LIGHTS 24 kw – 7.500 hours
KOHLER 17 kw – 300 hours
Fuel: 5.800 L
Water: 1.500 L
Water maker: HEM approx. 200 L per hour
Black & Grey Tank:  700 L
Sewage System: HAMANN MINI L-FRAME sewage treatment system

Boiler: 80 L
Refrigerator:  02 in galley + 01 in deckhouse
Deep freezer: 01 in galley
Wine cellar: in galley (refrigerated)
Air-conditioning/heater: in all cabins, saloon and pantry (2 units)

Electronic instruments: SIMRAD IS 15 Navigation System (log, echo sounder, course
Indicator, wind-strength and water-temperature indicators
Sounder: Interphace/Twincope Echograph
Self steering :           SIMRAD AP 20 Auto-Pilot
barograph: Meteo-Liner
Yacht monitoring: installed
Computer: Installed
Printer: HP – PSC 2210, all-in-one printer, photocopying machine &
Iridium: satellite telephone plus PC supported email function /
Microsoft Outlook
Mini M: SIMRAD MS 50 satellite telephone with BROTHER 1030 e telefax
SSB radio: Yes
VHF radio: SIMRAD RS Incl. DSC-Controller and watch receiver CH 70 at
Interior and exterior steering stand
+ 3 hand radio sets / SIMRAD HAT 50
DSC controller: JRC – JSB196 for intermediate and short wave
Radio telephone
Meteo: NCR – 300 NAVITEX - receiver
JRC – JAX – 9A Weather fax receiver
GPS: SIMRAD GN 33 GP-5 Navigator
Chart plotter: 02
Radar: SIMRAD CA 44 Multi-Radar at interior and exterior steering Stand

DECK AND COCKPIT
The hull is quite high on the water which gives a feeling of safety. The cockpit is very suited indeed with 2 steering stands and settees forward
Tender -stored between the inner stay and mast

ACCOMMODATION
3 guest double cabins aft and a large crew area up front which offers full privacy for guests and crew. Crew have their own access from the front deck.
Master cabin with double bed & sofa (can be used as child’s bed)
1 guest cabin with 2 single beds and additional folding bed
1 guest cabin with 2 bunk beds
2 crew cabins with 2 bunk beds each
Air-conditioning/heater in all cabins

DOMESTIC EQUIPMENT
Miele dishwasher, washing Machine and dryer

ENGINE ROOM
Located below the main saloon with access through a door located near the bottom of the stairs leading from the guest cabins to the main saloon.

COMMUNICATION EQUIPMENT
Iridium: satellite telephone plus PC supported email function / Microsoft Outlook
Mini M: SIMRAD MS 50 satellite telephone with BROTHER 1030 e telefax
SSB radio :
VHF radio: SIMRAD RS Incl. DSC-Controller and watch receiver CH 70 at interior and
exterior steering stand
3 hand radio sets / SIMRAD HAT 50
DSC controller & radio telephone installation:   JRC – JSB196 for intermediate and short wave

ENTERTAINMENT
Boose Sound system
03 TV in master stateroom, main saloon and crew mess
TV Satcom antenna

SAFETY AND SECURITY
02  x 8 people Life rafts
Fire extinguishers

PLUMBING AND TANKS
Water maker: HEM approx. 200 L per hour
Black & Grey Tank:  700 L
Sewage System: HAMANN MINI L-FRAME sewage treatment system

ELECTRICITY
4 MASTEVOLT chargers + 2 inverters
Generator      24 KW NORTHERN LIGHTS
17 KW KHOLER
Shore power
Battery: engine, generator and service
MOORING CQR Niro anchor 108 kg, with 120m chain, 16mm
Stern & reserve anchors
hydraulic anchor windlass

TENDER
Tender: Zodiac 4m + 40 HP Yamaha with new seat covers

MISCELLANEAOUS EQUIPMENT
New hydraulic gangway
Compressor with 4 diving tanks

Recent Equipment upgrades including:
Serviced: Air Conditioning
hydraulic pumps
boiler
diving compressor
bow thruster
New Electronic Control Panel
New Windlass
New running rigging
New heads on rod rigging
Refitted head mast
New awning
New hydraulic gangway
Mast head redone

013



Download as PDF



IMPORTANT: The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct their agents, or their surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
