NEW BUILD - 15m Tug Boat FIFI



Listing ID:
2240

DESCRIPTION:NEW BUILD - 15m Tug Boat FIFI
DATE LAUNCHED:Built to Order
LENGTH:14.95m (49ft)
BEAM:5m (16ft 4in)
DRAFT:1.7m (5ft 6in)
DISPLACEMENT:43.62 tons
LOCATION:ex factory, Turkey
BROKER: Richard Pierrepont

Send Enquiry


General Description:

Please scroll down to view more photos


DIMENSIONS
Length OA: 14.95 m
Beam OA: 5.00 m
Depth at sides: 2.21 m
Draught Aft: 1.70 m
Displacement: 43.62 tons

TANK CAPACITIES
Fuel-Oil: 11.49 m3
Fresh Water: 2.92 m3
Grey Water: 0.66 m3

PERFORMANCES
Bollard Pull: 10+ ton
Speed: 12.2 Knots

PROPULSION SYSTEM
Main Engines: 2x Cummins QSM11 660
Total Power: Rated at 669kW (910hp) at 2000rpm
Gear Boxes: 2x Twindisc 5114 1:4.1
Propulsion: 2x Eris Fixed Pitch Propellers 1300mm Diameter

AUXILIARY EQUIPMENT
Main Generator: 130 /400V 27kVA, 50hz
Pumps: Bilge/GS/Fire

DECK LAYOUT
Anchor: 2x 60kg Pool (High Holding Power)
Chain: 2 x 70m 12mm
Anchor Windlass: Data Hydraulic

NAUTICAL AND COMMUNICATION EQUIPMENT
Search Lights: 250W
Compass: Standart
VHF: Raymarine Ray55
GPS: Raymarine C80
Echosounder: Raymarine D50 3D
Radar: Raymarine 24nm

2240: NEW BUILD - 15m Tug Boat FIFI -  095

Download as PDF



IMPORTANT: The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct their agents, or their surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
