Seaboats Main > Commercial Vessels > Tugs >

2 units of Tug 23.65m 1000 HP 2009



Listing ID:
1465

DESCRIPTION:2 unit Tug 23.65m 1000 HP 2009
DATE LAUNCHED:2009
LENGTH:23.65m (77ft 7in)
BEAM:7m (22ft 11in)
DRAFT:2.60m (8ft 6in)
LOCATION:Samarinda, Indonesia
BROKER:Richard Pierrepont

Send Enquiry


General Description:

Please scroll down to view more photos


Year of Build: 2009
Place: Samarinda
Flag: Indonesia
Class: BKI

LOA: 23.65m
Breadth Moulded: 7m
Draft (design): 2.60m
Depth Moulded: 3.15m
Service Speed: 8 knots
Bollard Pull: 8 tons
Complement: 10 persons

ENGINE
Main Engine: 2 unit Yanmar 6 HYM - ETE, 1800 rpm, 500hp
No. Seri: 0970 (58), 0912 (PS)
Gear box: 2 unit hangZhou Fada JD 400 A
Ratio: 1:5

Fuel Consumption: 2 unit main Engine: 115.15 Ltr/h ( normal speed 1500 rpm )
1 unit AE 12.02 Ltr/h, 1 unit Emergency Genset 2.68 ltr/h
1 unit Fifi Engine 113.68 Ltr/h

AUXILIARY ENGINE
Mesin / motor diesel: 2 unit MITSUBISHI 6D14
Daya Putar: 1500 rpm
Jumlah Cylinder: 6 (enam) Cylinder
No. Seri: 258932 (SB) & A 90313281 (PS)

EMERGENCY GENSET
Merk / type: 1 unit Engine Daesung S11ONM & Generator General STC 10
Kapasitas: 10 kva
Putaran: 1500 rpm
No. Seri: 27908

Steering Wheel: Electric - Hydraulic ( Aft & Fwd )

Fuel Oil Tank Capacity: 50.06 M3 ( 2x18.99 M3, 2x4.93 M3 & 1x2.24 M3)

Fresh water Tank capacity: 49.94 M3 ( 2x6.84 M3 & 2x18.13 M3 )

NAVIGATION & COMMUNICATION EQUIPMENT
Magnetic compass: 1 unit Daiko Magnetic Compass T1508B 6” (Table Type)
Radar: 1 unit Furuno marine Radar 1715
Echo Sounder: 1 unit Furuno FCV - 620 5, 6” color LCD
GPS: 1 unit Furuno GPS GP-32 Video Plotter
VHF Marine Transceiver: 2 units ICOM VHF Marine radio Trans IC - M34
SSB: 1 unit ICOM SSB Radio Telephone IC-718
Two Way VHF: 2 units ICOM VHF Marine radio Trans IC - M34
Rudder Indicator: 2 units VDO ( Aft & FWD )

SAFETY EQUIPMENT
Ring Buoy: 6 units Fiber c/ w  line & light
Life Jacket: 24 units c/w whistle & light
Inflatable Life craft: 2 unit cap. 10 persons c/ w hydrostatic release & pelican hook
Red hand Flare: 6 units
Parachute: 4 units
Smoke signal: 2 units
Line Throwing Apparatus: 1 unit
Fire Blanket: 1 unit
Smoke & Heat Detector: DC Power c/ w control panel 1 set
Fire Extinguisher: 4 units Dry Power 6 kg, 2 units Foam 9 Ltr & 2 units CO2 Portable 6kg
CO2 System: 2 units CO2 45kg c/ w panel alarm system & emergency release
Bilge Alarm System: 2 units detector c/ w panel alarm system
Fireman Outfit: 3 units c/ w 2 units SCBA 6Ltr

ENGINE ROOM PUMP
Fire Fighting Pump: 1 unit master Pump SBS 250-600B cap, 1200 M3/ jam c/ w 2 units Fire Monitor cap, 400 M3/ jam
Engine: 1 unit Volvo D16C-AMH/ 7500hp/ 1800 rpm
Bilge Pump: 1 unit Master Pump Y2-100-L-2 cap, 24 M3/jam
General Service Pump: 1 unit master Pump 80ZX43 - 17 cap, 33 M3/ jam
FW Pump: 1 unit Hitachi WT-P300ST cap.0.25 M3/jam
Fuel Oil Transfer Pump: 1 unit Tusahaco Pump RT40 cap. 2.5 M3/jam
Portable Bilge Pump: 1 unit

DECK EQUIPMENT
Anchor: 2 units stockless anchor x 240kg
Chain: 7 length
Anchor Windlass: 1 unit double gipsy hydraulic motor
Towing Hook; 1 unit Manual Towing Hook




1465: 2 unit Tug 23.65m 1000 HP 2009 - 090.jpg




Download as PDF



IMPORTANT: The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct their agents, or their surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
