216ft Anchor Handling Tug Supply Vessel



Listing ID:
2174

DESCRIPTION:216ft Anchor Handling Tug Supply Vessel
DATE LAUNCHED:1982
LENGTH:65.84m (216ft)
BEAM:12.8m (42ft)
LOCATION:USA
BROKER:John Kearns

Send Enquiry


General Description:

Please scroll down to view more photos


REGISTRATION
Hull: 741
Vessel Type: Anchor Handling Supply Vessel
Year Built: 1982

DIMENSIONS
Dimensions: 216 ft. X 42 ft. X 16 ft. (65.84 m X 12.8 m X 4.88 m)
Draft (Lightship): 7.99 ft. (2.44 m)
Draft (Maximum Operations): (13.8 ft. (4.21 m)
Loadline Displacement: 4,854.42 LT (4,932.32 MT)
Clear Deck: 108 ft. x 32 ft. (32.92 m x 9.75 m)
Cargo Deck Area: 3,456 sq. ft. (320.97 sq. m)
Deck Cargo Capacity: 966 LT (981.5 MT)
Deadweight Tonnage: 1,149.88 LT (1,168.33 MT)

CAPACITIES
Fuel Oil: 196,994 gals. (745.7 cu. m)
Ballast: 219,417 gals. (830.58 cu. m)
Fresh Water: 14,630 gals. (55.38 cu. m)
Bulk Mud: 6,000 cu. ft. @ 80 psi (169.9 cu. m @ 5.5 bars)
Liquid Mud: 2,222 barrels (353.27 cu. m)

MACHINERY
Main Engines: Two (2) EMD 16-645E7BA, 6,140 BHP
Propulsion: Two (2) Convention with Kort
Bow Thrusters: One (1) Bird Johnson 35/3S/FP, 535 HP
Generators: Two (2) x 150 kW

TOWING AND ANCHOR HANDLING (DECK EQUIPMENT)
Winches: Brattvaag double drum Waterfall, 180 MT per drum
Chain Lockers: Four (4) x 3,000 ft. of 3 in. (914.4 m of 76.2 mm)
Storage Reels: Four (4) 4,107 ft. of 2.5 in. wire each

SPECIAL FEATURES
Shark Jaws: One (1) 300 MT
Tow Pins: One (1) 150 MT
Tuggers: Two (2) x 10 Tons (9.07 MT)
Stern Rollers: One (1) 5 ft. x 8 ft. (1.52 m x 2.44 m)

LIFE SAVING EQUIPMENT
Life Rafts: Two (2) x 20-Man Inflatable Life Rafts
Rescue Boat/Craft: One (1) Rescue Boat
Rescue Litter: One (1) x Rescue Litter
Other gear as required by authorities

ELECTRONICS
Electronics Package: Two (2) Furuno Radars, Two (2) Sailor FM Radios, Sea SSB (Single Sideband Radio), Furuno Fathometer, Sperry Autopilot, Sperry Magnetic Compass, Furuno Loran, Sperry Gyro Compass, Sea Emergency Radio

CLASSIFICATION
ABS: Maltese Cross A1 (Towing Service)
ABS: Maltese Cross AMS
ABS: Loadline
ABS: DPS-2

ACCOMMODATIONS
Accommodations:  42


2174: 216ft Anchor Handling Tug Supply Vessel - 095.jpg
